LED Surface-Mounted Luminaire

LEANLED II

Very slim, very bright, electrically linkable

The bright LEANLED II striplight can be used in almost any machine without the presence of flying metal chips or coolants and lubricants. The splinter-free cover made of polycarbonate protects the LED technology from dust and splash water.  Further versions can be arranged in a cascade. These versions can be interlinked electrically, enabling easy and quick installation of a lighting system, which illuminates large production areas with a homogeneous and uniform light pattern.
Like the previous model, the LEANLED II is available with clear or opal white cover. Three length options have been added, which allow you to choose between seven lengths. It is important to highlight the new, supplied brackets, which allow the striplight installation to be either fixed or movable.
For all those who want to expand their stock of the previous LEANLED model, the LEANLED striplight in a surface-mounted version can be found here: LEANLED surface mounted

Attributes Icons | LED Machine Light | LED Bar Light | LEANLED II | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK
Slider | LED Machine Light | LED Surface Mount Light | LED Bar Light | LEANLED II | coming soon | LED2WORK

YOUR BENEFITS

  • Extremely intense LED striplight
  • Uniform, flicker-free illumination
  • Homogeneous illumination via opal-white glare shielding
  • Cascadable, i.e. electrically linkable versions – thus easy power supply of multiple luminaires via a single power supply line.
  • Versatile use

AREAS OF APPLICATION

  • Woodworking
  • For machines and systems with a lack of space
  • Dry work areas in metal working shops
  • Automated systems and bending machines
  • Punching machines and conveyor belts
  • Logistics and many other applications

THE TECHNOLOGY

  • Intense illumination in daylight white 5200-5700K
  • Beam angle 120° and color rendering Ra >85
  • Slim, almost flush-mounted LED luminaire, only 25mm high
  • Clear or opal white cover made of polycarbonate, crack-proof and splinter-proof
  • Heat is dissipated to the rear via aluminium base body
  • IP 54 rating and long lifespan > 60,000h (L80/B10)
  • Supply voltage 24V DC and an A-coded M12 connector
  • Cascadable versions with M12 connectors for electrical interlinking
  • CE and ETL listed
  • 2 pairs of luminaire holders for fixed or swivel mounting included in the scope of delivery
  • Maintenance-free, 36-month warranty
  • Made in Germany

Designs

  • 7 lengths: 180mm, 260mm, 350mm, 520mm, 760mm, 1020mm, 1520mm
  • 2 versions: LED luminaire with clear cover or opal-white glare shielding
  • 2 versions: LED striplight as a standalone unit or electrically linkable
  • Installation options: supplied light holders (2 pairs) for fixed or movable mounting or via optional mounting accessories

Hinweis: Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube. Mehr Erfahren

The LED rod luminaire LEANLED II

LEANLED II and SIGNALED II RGB have the same basis: as a basic body slim aluminum profile with a shatterproof cover over the LED chips. While LEANLED II emits strong white light, the light of SIGNALED II RGB can be displayed in all colors of the RGB color space. White light can be produced by mixing RGB colors if required.

Both LED lights are available in 7 lengths, each supplied with two pairs of holders to choose from.


LED Machine Luminaire | LED striplight

All LEANLED II models:

Article number Power consumption Lamp luminous flux Data sheet
LEANLED II, 180 mm (7,09“), clear cover 111010-01 ~4 W 668 lm Data sheet
LEANLED II, 260 mm (10,24“), clear cover 111010-02 ~6 W 1000 lm Data sheet
LEANLED II, 350 mm (13,78“), clear cover 111010-03 ~8 W 1336 lm Data sheet
LEANLED II, 520 mm (20,47“), clear cover 111010-04 ~13 W 2004 lm Data sheet
LEANLED II, 760 mm (29,92“), clear cover 111010-05 ~19 W 3004 lm Data sheet
LEANLED II, 1020 mm (40,16“), clear cover 111010-06 ~24 W 4008 lm Data sheet
LEANLED II, 1520 mm (59,84“), clear cover 111010-07 ~37 W 6012 lm Data sheet
Article number Power consumption Lamp luminous flux Data sheet
LEANLED II, 180 mm (7,09“), opal white cover 111010-11 ~4 W 668 lm Data sheet
LEANLED II, 260 mm (10,24“), opal white cover 111010-12 ~6 W 1000 lm Data sheet
LEANLED II, 350 mm (13,78“), opal white cover 111010-13 ~8 W 1336 lm Data sheet
LEANLED II, 520 mm (20,47“), opal white cover 111010-14 ~13 W 2004 lm Data sheet
LEANLED II, 760 mm (29,92“), opal white cover 111010-15 ~19 W 3004 lm Data sheet
LEANLED II, 1020 mm (40,16“), opal white cover 111010-16 ~24 W 4008 lm Data sheet
LEANLED II, 1520 mm (59,84“), opal white cover 111010-17 ~37 W 6012 lm Data sheet

LEANLED II klar kaskadierbar

Article number Power consumption Lamp luminous flux Data sheet
LEANLED II, 180 mm (7,09“), clear cover, cascadable 111010-21 ~4 W 668 lm Data sheet
LEANLED II, 260 mm (10,24“), clear cover, cascadable 111010-22 ~6 W 1000 lm Data sheet
LEANLED II, 350 mm (13,78“), clear cover, cascadable 111010-23 ~8 W 1336 lm Data sheet
LEANLED II, 520 mm (20,47“), clear cover, cascadable 111010-24 ~13 W 2004 lm Data sheet
LEANLED II, 760 mm (29,92“), clear cover, cascadable 111010-25 ~19 W 3004 lm Data sheet
LEANLED II, 1020 mm (40,16“), clear cover, cascadable 111010-26 ~24 W 4008 lm Data sheet
LEANLED II, 1520 mm (59,84“), clear cover, cascadable 111010-27 ~37 W 6012 lm Data sheet

LEANLED II opalweiß kaskadierbar

Article number Power consumption Lamp luminous flux Data sheet
LEANLED II, 180 mm (7,09“), opal white cover, cascadable 111010-31 ~4 W 668 lm Data sheet
LEANLED II, 260 mm (10,24“), opal white cover, cascadable 111010-32 ~6 W 1000 lm Data sheet
LEANLED II, 350 mm (13,78“), opal white cover, cascadable 111010-33 ~8 W 1336 lm Data sheet
LEANLED II, 520 mm (20,47“), opal white cover, cascadable 111010-34 ~13 W 2004 lm Data sheet
LEANLED II, 760 mm (29,92“), opal white cover, cascadable 111010-35 ~19 W 3004 lm Data sheet
LEANLED II, 1020 mm (40,16“), opal white cover, cascadable 111010-36 ~24 W 4008 lm Data sheet
LEANLED II, 1520 mm (59,84“), opal white cover, cascadable 111010-37 ~37 W 6012 lm Data sheet

With through-wiring (cascadable), several luminaires can be electrically linked.

The total current consumption must not exceed 4 A DC at ta max. + 40 °C.

Product Accessories

LEANLED / SIGNALED Luminaire support, spring clip (1 pair)
LEANLED / SIGNALED Luminaire support, spring clip (1 pair)
Item No.: 210200-07
LEANLED / SIGNALED Luminaire holder, spring clip with magnet (1 pair)
LEANLED / SIGNALED Luminaire holder, spring clip with magnet (1 pair)
Item No.: 210200-08
LEANLED II/SIGNALED II luminaire holders (2 pairs)
LEANLED II/SIGNALED II luminaire holders (2 pairs)
Item No.: 210200-18
Adapter for luminaire holder LEANLED II/ SIGNALED II, 1 pair
Adapter for luminaire holder LEANLED II/ SIGNALED II, 1 pair
Item No.: 210200-19

2 pairs of holders (included). For power supplies and connection material, see accessories.
